-4-

598-1143-02

DANGER: Electric shock hazard. Do not open chime. No serviceable

components inside. If strobe fails to ﬂash, replace chime.

Troubleshooting

A. Chime does not sound and strobe does not ﬂash:

• Makesurepushbuttonandchimecodesarethesame(seeFigure5).

• Checkorientationofpushbuttonbattery(Seediagraminsidepushbutton

for correct battery orientation.)

• Checkchargeofpushbuttonbattery,replaceifnecessary.

B. Chime sounds when not intended (false triggers): Chime is receiving

interference from anotherwireless device; change the code setting(see

Code Settingbelow).

C. Batteries seem OK, but the chime and strobe do not work when in-

stalled:

• Donotmountchimeorpushbuttononmetalornearmetalstuds.This

reducesthetransmitterrange.Use1/4"to1/2"(6to13mm)woodshims

to move chime or push button off metal surface.

• Concreteoorsmayreducerange.Movechimeawayfromoor.

• Trylocatingchimeclosertopushbutton.

D. Code Setting:

WARNING: Disconnect chime unit from power source before

opening code access door. Close door and replace screw before

reconnecting to power.

It is recommended to only change one code position at a time and then check

to see if system is functioning properly.

1. Unplugchimefrompowersource.

2. Open the cases and locate the jumpers on both the push button and chime

(see Figure 5).

3. The push button has eight different jumper locations and the chime has

seven different jumper locations. Jumper positions 1 through 7 are used for

setting the code.
