I
..+:,
I
6
tU G
IiR[IINAL
STRIP
-
Pase22
ry
Qo:znur
()
()
()
()
At 1-1lS"
from one
end of
the
strip,
notch out
the
insulating
paper
so it
will
fit
snugly
around
the
transformer
mounting
foot at
AK and be
centered
under the terminal
strip as shown
in Pictorial
8.
Remove the white
protective
backing
from
the
gray
insulating
paper
and
(keeping
the
adhesive
off
the
chassis as
much as
possible)
slide
the strip
under
the
terminal strip
with
the adhesive
side down.
Then
press
the
paper
onto
the chassis.
Remove the
protective
backing
paper
from the
fuse
replacement
label and
press
the adhesive
side
of
the
label against the
chassis as shown
in
Pictorial
8.
Temporarily set the
chassis aside.
6
LOCKWASHiR
I
l!
-
l_-n
'c--'
3lIb
SPACER
N
DetailSQ
NOTE: The 5-lug terminal strip
in the
following
step
is the
one
pre-wired
earlier.
For
clarity,
Detail
8Q
does
not show
the
prewiring.
(
)
Refer to
Detail
80
and
mount
the
power
transformer
on the bottom of
the chassis.
Use 6-32
x 3/8"
hardware. Place the 6-lug
terminal strip
at AK and
the
pre-wired
S-lug teifi-nal
strip
at AL. Be sure
to
position
th66-ounting
foot of each
terminal strip
as
shown.
Use lockwashers
under each
transformer
mounting
foot
as shown,
(
)
Insert the ends of both
green
twisted
pairs
through
grommet
AM and
pull
the
pairs
up through
the
grommet
to the top of
the chassis.
Do not
pull
the
pairs
so tight
that there
is
any
strain
on
the
connections
to the terminal
strip.
The loose
ends of
these
pairs
will be connected
later.
(
)
From
the
gray
insulating
paper,
cut off a strip
1"
wide
to
form
a
piece
1"
x
2'314".
Save
the remaining
paper
for
use
later.
6
32 x \12
SCRTI1I
Detail9A
SUBPANEL
ASSEMBLY
Refer to
Pictorial
9
(fold-out
from
Page 25)
for
the
following steps.
(
)
Refer
to
Detail
9A
and mount a
white
pulley
on the
subpanel
at M as
follows:
1.
Insert
a 3/16"
long
spacer
and a 6-32
x
1l2" screw
into the
pulley.
2.
Place
a 6-32
nut on the screw
and
tighten it
until
it
just
touches the spacer.
3.
Place
a #6
lockwasher on the screw.
4.
Place
the screw of
the
pulley
assembly
into
hole
M on
the back
(unpainted)
side of
the subpanel
and secure
it
with a 6-32
nut on the
front of the subpanel.
Tighten
this nut securely,
5.
Make
sure
the
pulley
still
turns
easily on
the spacer.
&'l,,;J'l'
r.-d}
