Heathkit SW-7800 - Final Assembly

kit
Heathkit
Page
101
FINAL
ASSEMBLY
Refer
to
Pictorial
8-1
for
the
following
steps.
Locate
the
bottom
cover
(the
cover
without
the
1/2"
hole
near
one
corner).
Carefully
peel
the
backing
paper
from
one
of
the
feet.
Then
refer
to
inset
drawing
#1
on
the
Pictorial
and
press
the
foot
onto
the
bottom
cover
in
the
area
shown,
Similarly,
press
feet onto
the
bottom
cover
near
the
other
three
corners.
Position
the
bottom
cover
on
the
Receiver
as
shown
so
the
holes
that
are
closer
to
the
edges
of the
cover
are
toward
the
front
panel.
Then
use
two
6-32
x
3/8"
screws
to
secure
the
front
of
the
cover
to
the
chassis.
Use
two
#6
x
3/8'
sheet
metal
screws
to
secure
the
rear
of
the
cover
to
the
chassis,
Install
a
1/2"
rubber
grommet
in
the
1/2"
hole
n
the
top
cover
This
completes
the
“Final
Assembly.”
Installation.”
Position
the
top
cover
on
the
Receiver
as
shown.
Then
use
two
6-32
3/8”
screws
and
two
#6
sheet
metal
screws
to
secure
the
cover
to
the
chassis.
Push
the
indicated
end
of
the
collapsable
an-
tenna
into
the
rubber
grommet
in
the
top
cover.
Then
turn
the
antenna
onto
the
screw
mounted
on
the
chassis. Tighten
the
antenna
only
finger
tight.
Carefully peel
the
backing
paper
from
the
blue
and
white
label.
Then
refer
to
inset
drawing
#2
on
the
Pictorial
and
press
the
label
onto
the
rear
panel in
the
area
shown.
Be
sure
to
refer
to
the
numbers
on
this
label
in
any
com-
munications
you
may
have
with
the
Heath
Company
about
your
kit
Proceed
to
