from being started accidentally (disconnect the spark plug / disconnect the power
unit from the mains / if the machine is equipped with a trigger key, remove it).
Wear gloves when handling the blades. Risk of cuts.
THIS WARNING IS NOT REPEATED IN ANY FOLLOWING POINTS!
MULCHING
(the grass is cut in one working step, then finely chopped and returned to the grass
strip as natural fertilizer).
1. Lift the back cover and remove the basket (fig. 18A).
2. Place a mulching wedge into the discharge channel (fig. 18B).
3. Snap the mulch wedge lock into the top of the discharge opening (fig. 18C).
4. Close the back cover.
• Use a sharp cutting knife.
• Mulch only dry grass, do not try to mulch wet or damp grass.
• Regularly clean mulching wedge, housing inner side and mowing blade.
• Mow regularly, up to 2 cm (ie shorten from about 4 cm to 6 cm).
BASKET COLLECTION
1. Remove the mulching wedge, fit the collection basket (as described above) (fig. 8).
SIDE GRASS EJECTION - ONLY HECHT 5045 S
1. Lift the back cover and remove the basket (fig. 18A).
2. Place a mulching wedge into the discharge channel (fig. 18B).
3. Snap the mulch wedge lock into the top of the discharge opening (fig. 18C).
4. Lift sideward flap for side discharge (fig. 19A).
5. Mount the discharge guide for side discharge on the support pin of the sideward flap
(fig. 19B).
6. Lower the sideward flap - the flap lies on the discharge channel (fig. 20).
INSTRUCTIONS FOR USE
BATTERY RUNTIME
• Battery runtime depends on lawn conditions, grass density, moisture content, grass length
and height of cut.
• Switching the machine on and off frequently during cutting will also reduce the battery
runtime.
• To improve the battery runtime it is recommended to cut more frequently, raise the cutting
height and walk at a normal pace.
• To increase the run time an additional battery can be purchased from an authorised
customer service.
