13 Tables and Overviews
336
Ethernet interface RJ45 socket (option)
Maximum cable length: Unshielded: 100 m
Shielded: 400 m
Pin Signal Description
1 TX+ Transmit Data
2 TX– Transmit Data
3 REC+ Receive Data
4 Vacant–
5 Vacant–
6 REC– Receive Data
7 Vacant–
8 Vacant–
Ethernet interface BNC socket (option)
Maximum cable length: 180 m
Pin Signal Description
1 Data (RXI, TXO) Inner conductor (core)
2 GND Shielding
13.2 Pin Layout and Connecting Cable for the Data Interfaces
