13 Tables and Overviews
338
13.3 Technical Information
Program memory
■
Hard disk with 1500 MB for NC programs
■
No limit on number of files
Tool definitions Up to 254 tools in the program or any number in tables
Programming support ■ Functions for approaching and departing the contour
■
On-screen pocket calculator
■
Structuring long programs
■
Comment blocks
■ Direct help on output error messages (context-sensitive)
Programmable functions
Contour elements
■
Straight line
■ Chamfer
■
Circular arc
■
Circle center
■
Circle radius
■
Tangentially connecting circle
■
Corner rounding
■
Straight lines and circular arcs for contour approach and departure
■
B spline
FK free contour programming For all contour elements not dimensioned for conventional NC
programming
Three-dimensional tool radius compensation For changing tool data without having to recalculate the program
Program jumps
■
Subprograms
■
Program section repeats
■
Program as Subprogram
Fixed cycles
■
Drilling cycles for drilling, pecking, reaming, boring, tapping with a
floating tap holder, rigid tapping
■
Milling and finishing rectangular and circular pockets
■
Cycles for milling linear and circular slots
■
Linear and circular hole patterns
■ Cycles for multipass-milling of flat and twisted surfaces
■
Milling pockets and islands from a list of subcontour elements
■
Cylindrical surface interpolation
