Pocket table for tool changer
The TOOL_P table (for tool pocket) is programmed in a program run
mode of operation.
To select the pocket table:
ú
To select the tool table, press the TOOL TABLE soft
key.
ú To select the pocket table,
press the POCKET TABLE soft key
Set the EDIT soft key to ON
You can enter the following information on a tool into a pocket table
5.2 Tool Data
Column Input
P Pocket number of the tool in the tool magazine
T Tool number
ST Special tool with a large radius requiring several
pockets in the tool magazine. If your special tool
takes up pockets in front of and behind its actual
pocket, these additional pockets need to be locked in
column L (status L).
F Fixed tool number. The tool is always returned to the
same pocket in the tool magazine
L Locked pocket(see also column ST)
PLC Information on this tool pocket that is to be sent to
the PLC
Dialog
–
Tool number ?
Special tool ?
Fixed pocket ?
Yes = ENT / No = NO ENT
Pocket locked
Yes = ENT / No = NO ENT
PLC status?
Editing functions for pocket tables Soft key
Select beginning of table
Select end of table
Select previous page in table
Select next page in table
Reset pocket table
Go to the beginning of the next line
Reset tool number column T
Move to end of line
