6 – 172 HEIDENHAIN Technical Manual TNC 426, TNC 430
6.11.11 Status of HEIDENHAIN Inverters
All HEIDENHAIN inverters, except the UE 2xx compact inverters and non-
HEIDENHAIN inverters, provide the error signal ERR-IZ
in the event of an
excessive dc-link current at X69.
For HEIDENHAIN inverters except the UE 2xx compact inverters:
7
77
7 Activate the monitoring function for the ERR-IZ signal with
MP2221 bit 2 = 1.
After the monitoring function has been activated and the signal has appeared,
n The torque-producing current for the spindle is limited to 70 % of the
present current on the LE 426 M/12000 rpm
For HEIDENHAIN UE 2xx compact inverters and non-HEIDENHAIN inverters:
7
77
7 Deactivate the monitoring function for the ERR-IZ signal with
MP2221 bit 2 = 0.
After the monitoring function has been deactivated, the control continues
working until the inverter switches off.
With module 9066, further status information on the HEIDENHAIN inverters
can be read in the PLC.
MP2221 Current and speed controller monitoring functions
Input: Bit 2 –
0: Do not monitor ERR-IZ
signal, or inverter does not supply this
signal
1: Monitor ERR-IZ
signal
Module 9066 Status of HEIDENHAIN inverter
Call:
PS B/W/D/K <Code>
0: HEIDENHAIN inverter
CM 9066
PL B/W/D <Status information>
Bit 0: No function
Bit 1: dc-link voltage too high
Bit 2: Heat sink temperature too high
Bit 3: Short-circuit of a motor phase with U
Z
Bit 4: dc-link voltage too high
Bit 5: Power supply unit not ready
Bit 6: Leakage current too high
Error recognition:
Marker Value Meaning
M4203 0 Status has been read
1 Error code in W1022
W1022 2 Invalid code
24 Module was called in a spawn job or submit job
