Heinzmann PANDAROS II User Manual

9 Actuators
28 Digital Governor Basic System PANDAROS II
9.3 Specification
StG 2010.xx
StG 2040.xx
StG 2080.xx
Effective rotation at output shaft
36°
36°
36°
Max. torque at actuator output shaft
approx. 1.4 Nm
approx. 6.5 Nm
approx. 11 Nm
Torque in steady state condition
approx. 0.5 Nm
approx. 2.2 Nm
approx. 3.7 Nm
Response time 0-100 % without load
approx. 45 ms
approx. 50 ms
approx. 60 ms
Current consumption of whole
governor
maximum current
safe current in steady state
condition
approx. 4.5 A
approx. 1 A
Storage temperature
-55°C … +110°C
Ambiente temperature in operation
-25°C … +90°C
Ambiente temp., special application
-40°C … +90°C
Humidity
up to 100 %
Protection grade
housing
connectors
IP 65
IP 00 / IP 65
Weight
approx. 2.2 kg
approx. 3.9 kg
approx. 6.6 kg
