11 Electrical connection
Digital Governor Basic System PANDAROS II 35
11 Electrical connection
The electrical connection possibilities are depending on the variation of the control unit.
As the pin connections for the DG 6-00 variant support highly flexible configuration, a termi-
nal connection diagram for this purpose would be too unclear. In the case of this variant, the
potential connection options and functions of the inputs and outputs are therefore identified
using a table.
Terminal connection diagrams are available for all other variants.
The parameter settings for the configurable terminals and the functions of the individual pa-
rameters are described in detail in the publication
Basic information on control units for conventional injection via actuators, publication no.
DG 07 001-d.
11.1 Connection table for variation DG 6-00
CAN communication high-connection
CAN communication low-connection
Digital input 2 (switch to +24 V), or
Analogue input 2, 0 … 5 V or 0 … 10 V or 0 … 22 mA, or
PWM input 2, or
Digital output 2 (low side switched), or
Analogue output 2, 0 … 20 mA, or
PWM output 2
Digital input 1 (switch to +24 V), or
Analogue input 1, 0 … 5 V or 0 … 10 V or 0 … 22 mA, or
PWM input 1, or
Digital output 1 (low side switched), or
Analogue output 1, 0 … 20 mA, or
PWM output 1
GND for terminals 1 and 2
Temperature sensor signals
GND for temperature sensor
+5V reference supply voltage for setpoint potentiometer
Digital input 3 (switch to +24 V), or
Analogue input 3, 0 … 5 V or 0 … 22 mA, or
