11 Electrical connection
36 Digital Governor Basic System PANDAROS II
Terminal
Function
8
GND
9
Digital input 4 (switch to +24 V)
10
Error output (low side switched)
11
Digital input 5 (switch to +24 V), or
PWM input 3, or
speed sensor 2 (Halls ensor)
12
Speed sensor GND
13
Speed sensor signal
14
GND
15
Actuator feedback GND, pin E at actuator plug
16
Actuator feedback signal 1.6 ... 2.8 V, pin A at actuator plug
17
Actuator feedback + 8 V reference, pin D at actuator plug
20
Power supply GND
21
Power supply +24 V
24
Actuator drive line minus, pin B at actuator plug
25
Actuator drive line plus, pin C at actuator plug
11.2 Optional assignment of inputs and outputs, variation DG 6-00
11.2.1 Digital Inputs
The following parameters are available for assignment of digital inputs:
810 FunctEngineStop
811 FunctIdleSpeed
812 FunctDroop2Or1
813 FunctForcedLimit
814 FunctSpeedRange2Or1
815 FunctSpeedFix1
816 FunctSpeedFix2
817 FunctSpeedLimit2Or1
819 FunctNotch3
820 FunctNotch2
821 FunctNotch1
822 FunctNotch0
825 FunctSpeedInc
