4. Putting into Use for the First Time
4.1 Putting into use for the first time:
4.1.1 In order to enable cutting off power supply in dangerous situations, the battery plug (not included in
delivery) must be connected with the emergency stop plug of the truck.
Warning
The electric truck is not allowed to run without emergency stop plug.
4.1.2 The truck shall only be driven by battery power. Rectified AC power will damage the truck’s electric
components. Length of battery cable (towline) shall not exceed 6m.
4.1.3 If the truck is driven by an external battery through a towline, lifting will not be allowed.
4.1.4 Before putting the truck into use for the first time, conduct the following inspections:
a) Check whether the equipment is complete and in normal state.
b) If the truck has not been installed with battery, install battery and take care not to damage battery cable.
4.1.5 Adjust the characteristic curve (charging curve) of charger.
4.1.6 If the truck has been parked for too long a time, the ground plane of wheels may be flattened a little
bit; the flattened position will restore automatically after the truck travels for some distance.
4.2 If the order picker is not driven by its own driving devices:
Warning
Never drag the truck on a ramp.
4.2.1 In order to enable dragging the truck in emergency, the electromagnetic controlled brake must be
released.
4.2.2 After the truck has been parked at the appointed place, the electromagnetic controlled brake must be
fixed again so that the truck can return to a braked state.
5. Instructions for Use and Operations
The order picker adopts storage battery as its power source to travel and lift, used for picking cargo on
low/middle shelves; correct use and operations will bring great convenience for your work while incorrect
use and operations will damage the truck or cause danger to human bodies and cargo.
5.1 Before use:
Warning
Never use a faulted truck.
5.1.1 Check whether the truck is normal before use: whether hydraulic pipelines leak or not; each wheel
works normally or not; whether there is any stuck phenomenon; never use a faulted truck.
5.1.2 Check whether the storage battery is powered. Turn on the emergency switch and key switch on truck
frame, and turn on the emergency button on operation panel. Check BDI on the instrument panel. If the 0
grid is lighted, it shows the storage battery has run out of power and needs charging. Never use the truck
when it has run out of power, because it will shorten the battery’s service life greatly and even damage the
battery.
5.1.3 Check whether braking of truck is normal; check whether lifting, lowering, travelling forward/backward
and other movements are normal or not.
5.2 During use:
5.2.1 Press interlock button on the handle. For the right handle, pull it forward and the truck will move
forward; pull it backward and the truck will move backward; for the left handle, pull it forward and the truck
will turn to left; pull it backward and the truck will turn to right. If release the right handle and only pull the
