10.2 Truck transportation:
If the truck will be transported for a long distance, support the end of truck close to driver with wood
beam to make the drive wheels away from ground; fix the two front wheels with wood wedge, and fasten
the truck with the transportation vehicle with ropes.
10.3 Truck loading/unloading:
Before load or unload the truck, please first check the total weight marked on the nameplate, and
choose the proper hoisting device. Keep horizontal during hoisting and touch the ground slowly. People
around should take care, and the operation should be guided by another person. If load or unload with a
vehicle, first observe the bottom condition of the truck under loading/unloading. Operate cautiously when
the forks are inserted into the truck bottom to prevent forks from damaging the drive wheels, balance
wheels and front wheels of the truck.
11. Battery Replacement
Procedures for replacing battery are as follows:
Open and take down upper cover of truck;
Pull battery connector out of truck body;
Dismantle connecting wire of battery and take out the battery;
Procedures for mounting battery pack are the opposite.
Attention
When hoist or transport battery, handle it lightly, otherwise it may damage the battery or
human body.
12. Common Fault and Troubleshooting:
NO.
Fault
Cause
Troubleshooting
1
Order picker cannot start
(contactor doesn’t work,
either)
Fuse of control circuit burnt
Replace
Power switch has bad contact or
damaged
Repair or replace
Fuse of main circuit burnt
Replace
Electric lock switch has bad contact or
damaged
Repair or replace
Battery has loose connection or falls
Fasten
Order picker cannot start
(contactor works)
Brake of drive wheel does not close,
and the truck is in braked
condition
Repair or replace
Magnet exciting coil of travel motor
disconnected or has bad contact
Repair or replace
Contacts of contactor have bad
contacting performance
Repair or replace
MOSFET circuit board faulted
Repair or replace
Contactor does not contact well or
burnt
Repair or replace
2
Order picker can only
move forward (or
backward)
Circuit board faulted
Repair or replace
Contacts of contactor damaged;
moving contact does not restore
Cut off power supply
and replace contact
3
Braking failure
Brake has loose connection or burnt
Fasten bolts or repair
brake
Brake plate worn
Replace brake plate
