HELIX P SIX DSP MK2 User Manual

Connection to a PC
1
Load and save
2
Main menu
3
Channel configuration
4
Highpass filter
5
Lowpass filter
6
Time alignment
7
Output level
8
Frequency graph
9
Range of frequency graphs
10
Equalizer
11
EQ fine adjustment
8
1
6
3
4
7
5
2
9
10 11
25
It is possible to freely congure the HELIX
P SIX DSP MK2 with our DSP PC-Tool software.
The user interface is designed for easy handling of
all functions and allows an individual adjustment of
each of the eight DSP channels. Prior to connect-
ing the amplier to your PC visit our website and
download the latest version of the DSP PC-Tool
software.
Check from time to time for software updates.
You will nd the software and the respective user
manual on www.audiotec-scher.com.
We strongly recommend to carefully read the user
manual (Sound Tuning Magazine) before using the
software for the rst time in order to avoid any com-
plications and failures.
Important: Make sure that the amplier is not con-
nected to your computer before the software and
USB driver are installed!
In the following the most important steps how to
connect and the rst start-up are described:
1. Download the latest version of the
DSP PC-Tool software (available on our web-
site www.audiotec-scher.com) and install it
on you computer.
2. Connect the amplier to your computer using
the USB cable that is included in delivery. If you
have to bridge longer distances please use an
active USB extension cable with integrated re-
peater and no passive extension.
3. Turn on the amplier and start the software after
the Status LED lights up green. The operating
software will be updated automatically to the
latest version if it is not up-to-date.
4. Now you are able to congure your HELIX
P SIX DSP MK2 amplier with our intuitive
DSP PC-Tool software. Nevertheless interest-
ing and useful hints can be found e.g. in our
“Sound Tuning Magazine”, which can be down-
loaded for free from our website.
Important: We highly recommend to set the vol-
ume of you car radio to minimum position during
rst start-up. Additionally no devices or speakers
should be connected to the amplier until general
settings in the DSP PC-Tool software have been
made. Especially if the P SIX DSP MK2 will be used
to drive fully active speaker systems, a wrong setup
can destroy your tweeters right away.
