Operating Instructions • Bench Mount Kit AT2000 CPK • 03/2020 • 106-29020
Customer service and spare parts
14
11.2 Tool mount
124,5
158,5
9,3
63 65
149,5
40
22
6
Dimensions of the tool mount (all specifications in mm)
11.3 Base plate
260
20
5,3
20
260
20 20
Dimensions of the base plate (all specifications in mm)
11.4 Column
785
549,5
60
10020
12
Dimensions of the column (all specifications in mm)
11.5 Weight
Weight of the bench mount 9.54kg
Weight of the bench mount with cable tie reel 11.30kg
Weight of the bench mount with cable tie reel
and tool
13.00kg
12 Customer service and spare parts
If you have any questions or suggestions, please contact
HellermannTyton. The contact data is listed at the end of
this documentation.
