Helmer iPF125 - Horizon Series Parts; Appendix B

Helmer Scientic i.Series
®
and Horizon Series
™
Freezer - Upright Operation Manual
360369/A 26
Appendix B
Horizon Series™ Parts
Table 10. Horizon Series Parts and Description
Letter Description Letter Description
A Temperature Chart Recorder P Roll out basket
B Door lock Q Condenser grill
C Temperature monitor and control R Drain line fan
D Alarm key switch S Drain line heater
E Door handle with lock T Drain line
F Casters U Condensate evaporator
G Keypad (optional Access Control) V Water evaporation tray
H Back-up battery key switch (optional Access Control) W Remote alarm interface
I Magnetic lock (optional Access Control) X Main power switch
J Unit cooler with fan guard Y Circuit breakers (230 V only)
K Probe bottle Z Monitoring system back-up battery
L Cold-Shield door (Plasma storage models) AA Back-up battery (optional Access Control)
M Drawer BB Condenser
N Shelf CC Compressor
O Standard DD Access port (number and location vary by model)
Not
Show
Drawer/basket slide
* Temperature chart recorder is standard on plasma storage models, optional on laboratory models
END OF MANUAL
