7
Replacing the Battery
FIGURE 2-2
Only the HemoCue 201 DM Battery
can be used in the Analyzer.
Lithium-ion battery. Never try to open
the battery casing. Risk of explosion.
The Battery lasts for several years. It should
be replaced when it fails to retain its charge
for an acceptable period. Replace it when
the capacity to hold a charge starts to
deteriorate quickly.
a) To remove the Battery(1), press the
Flap(2). Carefully loosen the Battery(1)
and lift it upwards.
b) To install the new Battery(3), place it in
the Analyzer and gently press downwards
until the Flap(4) snaps into the locked
position.
Consult local environmental authorities for
proper disposal.
1 Old Battery
2 Flap
3 New Battery
4 Flap
1
2
3
4
