HemoCue Hb 201 DM User Manual

8
Connecting the Power Adapter
FIGURE 2-3
Only use the Power Adapter listed in
section Technical Specifications. Other
Power Adapters, although physically able to
be plugged into the Analyzer, may cause
serious damage or fire.
a) Insert the Power Adapter’s DC plug(2)
into the Power inlet(3) on the back panel
of the Analyzer.
b) Plug the Power Adapter(1) into an
electrical outlet.
1 Power Adapter
2 DC plug
3 Power inlet
3
1
2
