Model 8000 Computron
4-1. INFORMATION MODE 5. INP A_VHDSF_M
FUNCTIONS (Continued) Press to view the status of components and inputs. If the
input signal is detected, an identifying letter is displayed (see
below). If the signal is not detected, “_” is displayed.
With the COOK/PUMP switch in the COOK position, and all
inputs detected, “H_ P_ A_VHDSF_M” shows in the
display. See below for definition of codes.
A = COOK/PUMP switch in COOK position
B = COOK/PUMP switch in PUMP position
V = Volts – 24-VAC detected
H = High Limit - If “H” is present, the high limit is good;
if “H” is missing, the high limit is tripped (overheated) or
faulty
D = DRAIN SWITCH-If “D” is present, the drain handle is
Closed; if “D” is missing, the drain is open or faulty
S = COOK/PUMP switch on interlock circuit: If “S” is
present, the COOK/PUMP switch is in the COOK position;
if the “S” is missing, the power switch is either off, failed, or
wired incorrectly
F = FAN
P = PV – Detects 24 V jumper to PV terminal – gas fryers only
M = MV – Detects 24 V jumper to MV terminal – electric
fryers only
Press to view the specific status of each input. An
underscore (“_”) indicates the input is not presently detected.
A checkmark (“v” ) indicates the signal is detecting a normal
input. A blinking (“X”) indicates the signal is presently
detected, but is detected as a half-wave (partially failed)
input.
The V, H, D, S, F, P and M signals below are wired in
series. The first signal missing out of this sequence
generally causes all signals to the right of it to be
missing as well.
Press to continue on to OUTP H* P_.
4-4 103
