Henny Penny
Pressure Fryer
Model PFG-690
TECHNICAL MANUAL

Table of Contents

Questions and Answers

  • W
    William KaneAug 2, 2025
    Why is the product color not correct in my Henny Penny Fryer?
    • C
      Charles ThompsonAug 2, 2025
      The color of your fried product may be incorrect due to several reasons: * The temperature may be too high or too low. Check the temperature setting, and allow proper preheat time. * The shortening might be too old or too dark. Consider changing or filtering the shortening. * The temperature probe may be faulty; remove and replace it. * Breading the product too far in advance. Bread product closer to the actual frying period. * Low gas pressure; have gas pressure checked going to burners. * The wrong cook button was pushed. Be sure to select the correct amount of product to be cooked.
  • N
    Nicholas DavisAug 10, 2025
    What to do if the product color is not correct when using Henny Penny PFG-690?
    • C
      charles87Aug 10, 2025
      If the product color isn't correct, consider these potential causes: * Check the temperature setting in the program mode. * The temperature probe might be faulty; remove and replace it. * Change or filter the shortening if it’s too old or dark. * Adjust your breading process to be closer to the frying time. * Ensure proper preheat time. * Have the gas pressure checked if heat-up/recovery is slow. * Verify that you're selecting the correct cook button for the product amount.
  • K
    Karl ChavezAug 20, 2025
    How to fix incorrect product color in Henny Penny Fryer?
    • D
      davidwallsAug 20, 2025
      To correct the product color, consider the following: * Verify the temperature setting and preheat time. * Replace the temperature probe if faulty. * Change or filter the shortening. * Bread product closer to the actual frying period. * Check gas pressure if heat-up is slow. * Select the correct cook button.

Summary

Section 1. Troubleshooting

1-2. Safety

Explanation of safety alerts, DANGER, WARNING, CAUTION, and NOTICE.

1-3. Troubleshooting

Guidance on isolating malfunctions and using the troubleshooting table.

1-4. Error Codes

List of digital display error codes and their panel board corrections.

Section 2. Maintenance

2-3. Preventive Maintenance

2-4. High Temperature Limit Control

Procedure for checking and replacing the high temp limit switch.

2-5. Power;Pump Switch

Steps for checking and replacing the power/pump selector switch.

2-6. Temperature Probe Replacement

Instructions for replacing the temperature sensor and its fittings.

2-7. Complete Control Panel - Henny Penny

Procedure for replacing the main control panel assembly.

2-8. Pressure Regulation

2-9. Tilting the Lid Upright

2-10. Reversing the Lid Gasket

Instructions for cleaning and reversing the lid gasket for seal integrity.

2-11. Lid Counterweight Cables

Procedure for replacing the lid counterweight cables.

2-12. Pressure Pad

2-13. Lid Adjustment

2-15. Solenoid Valve

Procedure for checking and replacing the solenoid valve assembly.

2-16. Deadweight Valve

Information on the deadweight valve and its function in pressure regulation.

2-17. Removal & Cleaning of Safety Relief Valve

2-18. Pressure Gauge

2-19. Gas Control Valve

Safety precautions and procedure for replacing the gas control valve.

2-20. Blower Assembly

2-21. Transformer

2-22. Airflow Switch

2-23. Drain Microswitch

2-24. Drain Valve and Extension

2-25. Air Valve

2-28. Ignition Modules

Information on ignition module LEDs and replacement procedures.

2-29. Ignitor Assembly

2-30. Flame Sensor Assembly

2-31. Ignitor and Flame Sensor Adjustment

Critical adjustments for proper ignitor and flame sensor function.

2-32. Nylatron Strips Replacement

Henny Penny PFG-690 Specifications

General IconGeneral
ModelPFG-690
CategoryFryer
Heating MethodGas
ConstructionStainless Steel
Electrical60 Hz
Fry Area14 in (356 mm) W x 13.5 in (343 mm) D
