Heraeus UT 12 P - Starting Up with Added-Feature Programming Functions

4 OPERATION
Fig. 1/4: Example of a hot-air sterilization process
190 *C
S 1 - S 4 • Programmsegment
P3.5 P.onl
The heating is to switch on in 8 hours, the unit should heat up to 190 'C at 200 'C/h, maintain this
temperature for 4 hours, then switch off.
The program should start following program selection (P. o n).
Starting up with added-feature programming functions
|Key(s).
| Example of display | Remarks Instruction
Switch unit on, select operating temperature: refer to start-up with basic functions
Adjusting the overtemperature protection device: refer to Chapter 3
Control unit "oir, unit
should not heat up
during this input
-==—I approx. 3
>/ sec.
II
U I
Status display = "off",
control unit is disabled, Inside
temperature Is displayed
Call fixed program
memory
——I approx. 6
set sec.
Display flashes, program
segment S1 appears after 6
Select parameter PI. 3
I I I
Programmable digit flashes.
P I. Is displayed if no
parameter has been marked
U I _J
I L I
Programmable digit flashes
Mark P I. 3 as the
required parameter in
program segment S1
set
I I I
_
I. I
P I. 3 is transferred lo the
memory, programmable digit
flashes
Select program
segmenl S2
Programmable digit flashes
Continue In the same manner to enter / mark program segments P 2. 9, P 3. 5 und P 4.
