OPERATION
Fig. 3/4: Example of the programmed controller function with " hold " termination command
/
•4
T1
/
/
40%
n 1
100%
\
T2
•4
70%
n3
T3
nA
'hold
11 12
Starting up with programmed controller function
The "hold" termination command has been selected here as an alternative to example 2/4.
Enter the preset temperature, time and air speed level values for the program segments
according to the same procedure as example 2/4.
Instruction
Key(s)
Example of display
Remarks
Select program
segment n 4
I I
n 4 is displayed,
programmable digit
flashes
Select the "hold"
termination command
Transfer Ihe
termination command
lo the memory
prog
I i
"I "I
I I
Leave the program memory and slart the program
Termination command
flashes in the display
Enter the "hold"
termination command
n 4 is displayed,
programmable digit
flashes
26/34
50 042 750
Issue: May. 1994
