• Tighten the lock nut.
• Install the rear view mirror until it will
no longer turn.
• Adjust the rear view mirror.
• Loosen the rear view mirror approximately
2 turns.
Installation
(1) Dust cover (2) Lock nut
(3) Rear view mirror
1
2
NOTE
To open the right side rear view mirror, the
threads are to be loosened in clockwise
direction and tightened in counter clockwise
direction.
40
3
(f) Headlamp assembly
Removal
•
Remove the rear view mirror.
•
Remove screw (1) from front handlebar
cover (2).
(1) Screw (2) Front handlebar cover
2
1
(3) Screws (4) Rear handlebar cover
4
•
Remove the screws (3) on rear handlebar
cover (4).
• Pull the headlamp assembly (5) slightly up,
carefully release the tabs (6) from the slots.
Installation is in the reverse order of removal.
•
Loosen the rear view mirror (3) and
remove it.
•
Slide the dust cover up (1).
Removal
•
Loosen the lock nut (2) until it will no
longer turn.
(e) Rear view mirror
Installation
3
