Reinstall in the reverse order of removal. Be
sure to connect the (+)ve terminal first, then
the (-)ve terminal.
•
Check the bolts and other fasteners are
secured.
Battery installation
5
(5) Battery
•
Remove the battery (5).
The fuse holder (1) placed adjacent to the
battery which consist of main fuses and spare
fuses.
Main fuses (1) : 15A, 10A, 10A and 10A
FUSE REPLACEMENT
Fuse type: Blade fuse
Spare fuses (2) : 15A and 10A
1
(1) Fuse holder
(2) Main fuses : 15A, 10A, 10A and 10A
(3) Spare fuses : 15A and 10A
WARNING
!!
•
Never use a fuse with a different rating from
that specified. It may lead to serious damage
to the electrical system or a fire due to short
circuit.
•
Battery gives off explosive gases. Keep
sparks, flames & cigarettes away.
32
