INSTRUMENTS AND INDICATORS
The indicators are in the speedometer panel
above the headlamp. The functions are as
below :
PARTS FUNCTION
Sl. No.
1
2
3
4
5
Description
Function
Odometer
Shows accumulated distance travelled.
High beam indicator Light glows when headlamp is in high beam.
Speedometer Indicates driving speed.
Turn signal indicator Flashes when turn signal switch is operated.
When the fuel gauge needle (1) enters the red
band (2), fuel will be low and you should refill
the tank as soon as possible.
FUEL GAUGE
(1) Fuel gauge needle (2) Red band
6
Fuel gauge Indicates approximate fuel quantity.
Side stand indicator
Light glows when the vehicle is parked on the side stand.
54
3
2
1
14
6
21
