HERO PLEASURE+ - Body Parts Removal; Floor Side Cover Removal

31
•
Disconnect the left turn signal lamp
connector (3) and right turn signal lamp
connector (4).
•
Remove screws (2) from the inner side.
(1) Screws
1
2
(2) Screws
•
Open the seat (page 24).
•
Remove the rear grip (2).
Installation is in the reverse order of removal.
Ÿ Remove the center cover (2).
Installation
•
Remove the fuel tank cover (page 28).
Removal
(d) Rear grip
•
Remove the bolts (1).
(1) Bolts (2) Rear grip
1
2
•
Remove screws (1) from the front end of
the vehicle.
(e) Front upper cover
Installation is in the reverse order of removal.
Installation
Removal
