62
(4) Tail/stop lamp bulb
(3) Bolts
3
(c) Tail/Stop lamp bulb
•
Remove the rear grip (page 31).
•
Remove body covers (page 30).
•
Disconnect the seat catch cable (1) and
remove the tail/stop lamp cover (2)
•
Remove bulb holder with bulb by turning it
to clockwise direction.anti
(d) Rear turn signal bulb
•
Install the tail/stop lamp cover and connect
the seat catch cable.
• Remove the rear turn signal bulb (1) by
turning it to anticlockwise direction.
• Remove the rear center cover (page 31).
•
Install the rear grip .(page 31)
• Remove turn signal bulb holder with bulb by
turning anticlockwise.
•
Install a new tail/stop lamp bulb (4) in the
reverse order of removal.
•
Install the tail/stop lamp unit in the vehicle.
•
Install the body covers .(page 31)
•
Dismount the tail/stop lamp unit from
the vehicle by removing the bolts (3).
(1) Seat catch cable (2) Tail/stop lamp cover
1
2
4
•
Remove the bulb (4) from bulb holder by
turning it to clockwise direction.anti
