53
CAUTION
!!
•
Turn the ignition switch "OFF" before
checking or replacing the fuse to prevent
accidental short-circuiting.
•
Do not attempt to start or ride the vehicle
without a charged battery, it can cause
fusing of the bulbs and permanent damage
to certain electrical components.
•
Turn the ignition switch to the “ON”
position.
•
Remove the right pillion step cover
(page 51).
STOP LAMP SWITCH
The stop lamp switch (1) must be adjusted so
that stop lamp will glow when rear brake is
applied. Rear brake free play (page 42)
should be adjusted before performing stop
lamp switch adjustment. The procedure for
adjusting stop lamp switch is as follows:
(1) Stop lamp switch (2) Adjusting nut
(A) Advance (B) Retard
2
1
A
B
•
Park the vehicle on level ground.
HEADLAMP FOCUS ADJUSTMENT
Headlamp is factory preset. However in case
of adjustment required, please follow the steps
as given below:
•
Headlamp adjustment is done by the
headlamp adjusting bolt (1) located below
headlamp.
•
ampAdjust the headl beam vertically
by the loosening bolt & move the headlamp
unit forward & backward for correct focus
adjustment.
•
Turn the adjusting nut (2) to position stop
lamp switch at a point where the stop lamp
will glow just before the brake pedal is
depressed to the limit of its free play. Turn
the adjusting nut in direction (A) to advance
switch timing or in direction (B) to retard
switch timing.
