*Accessories and features shown may not be part of standard fitment.
7
TOP VIEW
(1) Trip meter knob
(2) Side stand indicator
(3) Headlamp dimmer switch
(4) Horn switch
(5) Turn signal switch
(6) Passing switch
(7) Rear view mirror
(8) High beam indicator
(9) i3s indicator
(10) Neutral indicator
(11) Speedometer
(12) Odometer
(13) Turn signal indicator
(14) Fuel indicator
(15) Trip meter
(16) i3s switch
(17) Front brake lever
(18) Throttle grip
(19) Electric starter switch
(20) Ignition switch with steering lock
(21) Fuel tank cap
11
13
14
VEHICLE VIEWS
1
2
3
4
5
6
7
8 9
10
12
15
16
17
18
19
20
21
