13
1
(1) Electric starter switch (2) i3s Switch
2
1
IMPORTANT: To switch “OFF” the turn
signal after completing the turn, gently push
the knob inside.
5. Horn switch ( )
Press the horn switch(5) to operate the horn.
Ÿ Never hold electric starter switch continuously
more than 5 seconds as continuous cranking
of engine will drain the battery.
CAUTION
!!
2. i3s Switch
There is an i3s switch provided to enable (2)
the rider for turning i3s mode “ON” or “OFF”
based on the traffic conditions.
(b) Right handlebar controls
1. Electric starter switch
Ensure starter switch ( ) is operated when the 1
vehicle is in neutral gear. If the vehicle is
engaged in gear, press the clutch lever before
operating the starter switch. Release starter
switch after the engine has started.
Ÿ During electric or clutch start, the engine
will cut-off if engine reaches 900 rpm if the
relay is engaged for more than 5 seconds.
i3s (Idle stop start system)
Starting & Warm up the engine:
Keep the i3s switch (1) to “OFF” position.
Turn the ignition key to “ON” position. The
i3s indicator (2) will glow on the speedometer
console for 2 seconds and turn “OFF”.
Start the engine and let it idle for 2-3 minutes.
(1) i3s switch
(2) i3s indicator
2
