12
4. Turn signal lamp switch ( )
Shift the turn signal switch(4) sideways for
Right/Left indications and leave it to come
back to its normal position on its own.
1
2
3. Clutch switch
There is a clutch switch (3) provided for the
safety of the rider. The vehicle cannot be
started by electric starter switch until the clutch
lever is operated when the vehicle is engaged
in gear.
5
4
FEATURES
Steering lock
Steering lock is with ignition switch. Put the
ignition key (1) to "OFF" position & turn the
handle bar towards left or right & push the key
downwards & turn towards "Lock" position.
After locking take out the key.
(1) Ignition key
1
HANDLEBAR SWITCHES CONTROL
(a) Left handlebar controls
(1) Passing switch (2) Headlamp dimmer switch
(3) Clutch switch
2. Headlamp dimmer switch
The headlamp operates only when the engine
is running or when passing switch is operated.
1. Passing switch
Gives an indication for passing ahead.
Functions in DC when the passing switch
knob is pressed in the following condition.
Ÿ Headlamp is “ON” in low beam due to
AHO.
Select “ ” for high beam and “ ” for low
beam.
(4) Turn signal switch (5) Horn switch
3
