Menu navigation and adjustment values
9
47
Term
Description
Unit
Tank 1 must
temperature
Setting up the set temperature (25-90) of tank 1
°C
Difference 1
Setting up the collector difference (5-30) of tank 1
°C
Tank 1 max.
temperature
Setting up the maximum temperature (25-95) of tank 1
°C
Tank 2 must
temperature
Setting up the set temperature (25-90) of tank 1
(→ only visible, if program number 3, 4, 5 or 6 is chosen)
°C
Difference 2
Setting up the difference (5-30) between collector and tank 1
(→ only visible, if program number 3, 4, 5 or 6 is chosen)
°C
Tank 2 max.
temperature
Setting up the maximum tank temperature (25-95) of tank 1 (→ only
visible, if program number 3, 4, 5 or 6 is chosen)
°C
Menu "Aggregate-Test"
Agg-Test
1
Collector pump*
Indicates the status of the collector pump:
▪ If the indicator lamp lights up, the collector pump is running
-
Loading pump*
Displays the condition of the loading pump
If the indicator lamp lights up, the collector pump is running
%
Switching valve OPEN
Display of the state of the switching valve OPEN:
If the indicator lamp lights up, the switching valve OPEN is activated.
-
Switching valve
CLOSE
Display of the state of the switching valve CLOSE:
If the indicator lamp lights up, the switching valve CLOSE is activated.
-
Menu „Solar-yield“
Yield
Actual yield
Display of the current yield
W
Daily yield
Display of the daily yield
Wh
Total yield
Display of the total yield
kWh
