INTRODUCTION
INFORMA 600 incorporates the following functions in one single equipment:
• Phone dialler on phone line and GSM network, to send voice and SMS messages*.
• GSM hands-free phone**
• Activation of remote access outputs
• Activation of GSM network outputs at zero cost*
• Activation of outputs by means of SMS with an answer to confirm the command
execution*
• Listen-in on GSM network**
• GSM network hands-free function*
• Scheduler for the automatic activation of holiday-programming outputs
• Extremely simplified programming with a guided menu by means of built-in key pad
and LCD display.
• Local and remote programming using a PC and the relating software
• Dialler software firmware updating
* only in PSTN + GSM version
** only in PSTN + GSM hands free version
■ Canali
FEATURES
There are 4 different channels to alarm the dialler and start the sequence of calls. Besides, there
are 3 other inputs:
- input 5: when activated, it forces the call onto the GSM line (only in PSTN+GSM
version)
- input 6: associated to a voice message, which can be heard only with remote
interrogation. It reports the alarm system status.
- the block input which, if activated at the moment, blocks the alarm and terminates
the cycle of calls.
It is possible to programme each input as: not used, normally open, normally closed.
■ Outputs
There are 5 different negative outputs (100mA current max.), divided as follows:
The first 2 outputs can be programmed and locally activated from the key pad and
LCD display, and remotely voice-activated, SMS messages or CLIP function (see
page12); output activating is at zero-cost (only for PSTN+GSM version). Output 3 is
enabled in case of phone line failure. Output 4 is enabled in case of failure / GSM
network lack of connection.
