BACK VIEW
8
Horizontal
Sockets
Vertical
Sockets
Isolated Power Supply System
INT - controls the power supply for Studio’s
internal functions; EXT - controls the power
supply for user devices. Please ensure both
buttons are pushed for full device functionality.
OCP Reset Button
Please see Over Current Protection
on p.19 for more details.
3D Cord Organization System
For advanced cable organization. Please see Cord and
Accessory Management on p.16 for more details.
Horizontal
Sockets
Surface Lock (Left&Right)
Prevent the aluminum surface from slipping
when devices are plugged. Please ensure both
locks are locked before using the devices (See
First Time Use on p.11 for more details).
