2.10 Relay
2.10.1 Physical features
 Single core magnetic latching relay
 Imax = 100A
 Operation life is a minimum of 5,000 times under rated current
 Operation life is a minimum of 10,000 times under no load condition.
 Pulse driven: In order to make sure that the relay can work properly, the voltage exerted
on the coil must reach rated voltage and the width of the pulse must be 3 times longer
than the operation time.
 Short time over current: 30Imax
 In order to operate the relay properly and not to cause a nuisance reset of the meter, the
meter only operates the relay when the supply voltage is higher than 70%Un.
2.10.2 Priority
Operation code
Priority level
Open Relay
Balance low, emergency credit
available
01
8
Balance low, emergency credit used
02
9
Overload
03
5
STS opening test
04
4
Meter cover open
05
6
Terminal cover open
06
7
Remote relay open
07
2
Factory default relay open
0B
10
Close Relay
