User manual- HXE310-KP
9
2. Main functions
2.1 Measuring functions
2.1.1 Energy measurement
 Measure Import & Export active energy, range: 000000.00～999999.99kWh
 Active energy measuring mode (Optional before leaving the factory)
 Mode 1: Consumption = Import + Export, Export = Export
 Mode 2: Consumption = Import, Export = Export
2.1.2 Instantaneous values
 Active power of Phase A, B and C
 Voltage of Phase A, B and C
 Current of Phase A, B and C
 Power factor of Phase A, B and C
 Grid frequency
 Phase angle of phase A and B, phase angle of phase A and C
2.1.3 Billing
When RTC of the meter pass the billing time, it will execute one billing record but not support
time-missing billing record.
 Monthly billing: records the last 12 months’ billing time, import active energy and export
active energy.
 Daily billing: records the last 62 days’ billing time, import active energy and export active
energy.
 Monthly billing (Prepayment): records the last 12 months’ billing time and credit balance.
 Daily billing (Prepayment): records the last 62 days’ billing time and credit balance.
 The monthly billing time is configurable as o’clock from the 1st to the 28th of every month,
with a format as XX day and YY hour (default 0:00 am of 1
st
). Daily billing time is
configurable with format as XX hour YY minute (default 0:00).
