Turntable Parts List
Machine
Section
HLI Part
Number
Item Description
Qty
1
300037
MOTOR VP3310D 1/4HP

1.5M
1
2
200091
SCREW M8X20L & W.
3
200092
SCREW M10x20L & S.W. & W.
4
4
300031
SPEED REDUCER 1/4HP

1.5M
1
5
300002
KEY 5X20L
1
6
200093
SCREW M10x25L & S.W. & W.
4
7
500034
MOTOR ADJUST SEAT

1.5M
1
8
500014
MOTOR PULLEY 4”22

1.5M
1
9
207303
SET SCREW, M8 x 10L
2
10
200095
SCREW M10x70L
1
11
200077
SCREW M6x12L & W.
1
12
500083
MOTOR BOX FIX PLATE
1
13
500087
PIN
2
14
300006
RING STW-10
2
15
600424
TURNTABLE SEAT WITH INTEGRAL SCALE - 1.5M
1
16
300009
RING STW-17
48
17
300021
BEARING 6203ZZ

1.5M
24
18
500010
SUPPORTING PLASTIC WHEEL

1.5M
12
19
500009
SUPPORTING PLASTIC WHEEL SHAFT

1.5M
12
20
300009
RING STW-17
1
21
300021
BEARING 6203ZZ
2
22
500011
BELT LOCK PULLEY
1
23
500012
BELT LOCK PULLEY SHAFT
1
24
200078
SCREW M6x16L
3
25
200098
SCREW M3x25L & W.
2
26
400641
PROXIMITY SWITCH PS-05N-3M
1
27
504280
PROXIMITY SWITCH FIX SEAT
1
28
200103
SCREW M4x20L
2
29
200128
NUT M5
6
30
300013
BELT B-172

1.5M
1
31
200113
SCREW M8x25L
4
32
500004
TURNTABLE TOP

1.5M
1
