Highlight Predator SS - Tower Assembly Diagram

Technical References Predator SS Turntable Stretch Wrapper Operation Manual
Highlight Industries, Inc. ● 2694 Prairie SW, Wyoming, Mi 49519 ● 1-800-531-2465 55
33
200084
SCREW M8x20L
4
34
500007
WHEEL 22”
1
35
504281
LOCATING PLATE
1
36
200108
SCREW M5x10L & W.
4
37
500008
PULLEY FIXING PLATE
1
38
500085
BELT PULLEY SEAT RING
1
39
300012
RING RTW-42
1
40
500084
BELT PULLEY SHAFT
1
41
300018
BEARING 6004ZZ
2
42
300010
RING STW-20
1
43
500086
BELT PULLEY BEARING SEAT
1
44
200088
SCREW M10x16L
4
45
200100
SCREW M4x8L & W.
4
46
500081
MOTOR COVER

1.5M
1
47
600028
TURNTABLE MOTOR BOX 1.5M
1
48
200100
SCREW M4x8L & W.
2
49
200140
JAM NUT – M12
REF
50
306276
LOAD CELL FOOT
4
51
306275
LOAD CELL
4
52
300353
SCALE DISPLAY (NOT SHOWN)
1
53
600947
RAMP – INTEGRATED SCALE (NOT SHOWN)
OPT
54
510287
SUMMING BOARD COVER (NOT SHOWN)
1
