Hikmicro CHEETAH LRF Series User Manual

Digital Night Vision Monocular User Manual
18
Chapter 7 Client Software Connection
Connect the device to the HIKMICRO Sight App via hotspot, then you can capture picture, record
video, or configure parameters on your phone.
Steps
1. Hold the wheel to show the menu of device.
2. Press to enable hotspot function.
3. Turn on the WLAN of your phone and connect to the hotspot.
● Hotspot Name: Wlan-IPTS Serial No.
● Hotspot Password: Serial No.
4. Scan the QR code to download and install the App.
Android System
iOS System
5. Open the App and connect your phone with the device. You can view the interface of device on
your phone.
Note
● The device cannot connect to the App if entering wrong password several times. Refer to
Restore Device to reset the device, and connect the App again.
● The device should be activated for the first use. The default password must be changed after
the activation.

Hikmicro CHEETAH LRF Series Specifications

General

Sensor Resolution	384 × 288
Display Resolution	1024 × 768
Detection Range	1800 m
Laser Rangefinder	Yes
Waterproof Rating	IP67
Frame Rate	50 Hz
Pixel Interval	12 μm
Laser Rangefinder Accuracy	± 1 m
Protection Level	IP67
Eye Relief	15 mm
Display	OLED
