Digital Night Vision Monocular User Manual
4
Note
The selectable types of the adapter are 38, 40, 50, and 62.
2.3Remove Adapter
Steps
1. Rotate only the locking ring clockwise, and make sure the device or other parts of the adapter
are not rotated or moved.
2. Plug out the adapter after it is loosen.
2.4 Install Daylight Scope
You can use the device together with a daylight scope to view the target clear in daytime.
Steps
1. Install the daylight scope into the transfer ring as arrow 1.
2. Lock the buckle to fix the daylight scope as arrow 2.
Figure 2-3 Install Daylight Scope
2.5 Install Battery
Insert the batteries into the battery compartment.
Steps
1. Turn the battery cover anticlockwise to loosen it.
