Hikmicro CHEETAH LRF Series User Manual

Digital Night Vision Monocular User Manual
20
Chapter 9 Unit Settings
You can switch the unit for the distance measurement function and the reticle function.
Steps
1. Hold the wheel to show the menu.
2. Rotate the wheel to select , and press the wheel to switch the unit. Yard and m are
selectable.
3. Hold the wheel to save settings and exit.

Hikmicro CHEETAH LRF Series Specifications

General

Sensor Resolution	384 × 288
Display Resolution	1024 × 768
Detection Range	1800 m
Laser Rangefinder	Yes
Waterproof Rating	IP67
Frame Rate	50 Hz
Pixel Interval	12 μm
Laser Rangefinder Accuracy	± 1 m
Protection Level	IP67
Eye Relief	15 mm
Display	OLED
