Hikmicro STELLAR Series User Manual

Thermal Image Scope User Manual
14
Figure 3-6 Set Picture in Picture Mode
Note
● When reticle is enabled, the PIP view is the detail of reticle. When reticle is not enabled, the
PIP view is the detail of central part.
● If the PIP function is enabled, the PIP view zooms when adjusting the digital zoom ratio.
3.10 Adjust Digital Zoom
In the live view mode, rotate the wheel to switch the digital zoom ratio of the device.
Steps
1. Hold the wheel to show the menu.
2. Rotate the wheel to select , and press the wheel to select a zoom mode.
– Continuous: In the live view mode, rotate the wheel to zoom in or zoom out by 0.1×
continuously.
– Multiple: In the live view mode, rotate the wheel to set the digital zoom ratio to 1×, 2×, 4×, or
8×
3. Hold the wheel to save and exit.

Hikmicro STELLAR Series Specifications

General

Pixel Size	12 μm
Frame Rate	50 Hz
Wi-Fi	Yes
Video Recording	Yes
Photo Capture	Yes
Resolution	384x288, 640x512
Display	AMOLED
Battery Type	Rechargeable Li-ion
Operating Temperature	-20°C to +50°C
Lens Options	19mm, 25mm, 35mm, 50mm
Focus	Manual
Color Palettes	Black Hot, White Hot, Red Hot, Fusion
