Thermal Image Scope User Manual
16
position for the reticle.
Before You Start
Select a reticle group first.
Steps
1. In the live view mode, hold the wheel to show the menu.
2. Rotate the wheel to select , and press the wheel to enter the reticle setting interface.
3. Press the wheel to select a reticle No. You can select OFF to disable the reticle.
4. Set reticle type.
1) In the reticle setting interface, rotate the wheel to select Type.
2) Press the wheel to select a reticle type. 10 types of reticles can be selected.
5. Set reticle color.
1) Rotate the wheel to select Color.
2) Press the wheel to switch the color of the reticle. Black, White, Green, and Red are
selectable.
6. (Optional) Repeat 3 to 6 to set color for other reticles in this group.
Note
When you switch the reticle No., a prompt will appear on the interface. Select OK to save the
parameters for the current reticle.
7. Hold the wheel to exit the interface according to the prompt.
– OK: Save the parameter and exit.
– CANCEL: Exit and not save the parameters.
Note
● There are 5 reticles can be configured in a reticle group.
● If the PIP function is enabled, the aimed target can be magnified on the interface.
