Table 3 Specification for DS-7200HFHI-ST
hard disk)
Working temperature
-10 ºC ~+55 ºC (14 ºF ~ 131 ºF)
Working humidity
10% ~ 90%
Chassis
Stand-alone 1U chassis
19-inch rack-mounted 1U
chassis
Dimensions
(W × D × H)
315×230×45 mm
(12.3×9.0×1.8 inch)
445×290×45mm
(17.3×11.3×1.8 inch)
Weight
(without hard disk)
2 kg / 4.4lb
4 kg / 8.8lb
Model
DS-7204HFHI-ST
DS-7208HFHI-ST
Video/Audio
input
Video compression
H.264
HD-SDI video input
4-ch
8-ch
HD-SDI interface (800 mVp-p, 75 Ω)
Supported HD-SDI
camera types
1080I60, 1080I50, 1080P30, 1080P25, 720P60, 720P50, 720P30,
720P25
Audio compression
G.711u
Audio input
4-ch
8-ch
RCA (2.0 Vp-p, 1 KΩ)
Two-way audio in
1-ch, RCA (2.0 Vp-p, 1 KΩ), (using the 1st channel of audio input)
Video/Audio
output
HDMI / VGA output
1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz,
1024 × 768 / 60 Hz
Encoding resolution
Main stream: 1080P / 720P / VGA / WD1 / 4CIF / CIF
Sub-stream: WD1(non-real-time) /4CIF(non-real-time) / CIF /
QCIF / QVGA
Frame rate
Main stream: 1/16 fps ~ Real time frame rate
Sub-stream: 1/16 fps ~ Real time frame rate
Video bitrate
32 Kbps-10 Mbps
Audio output
1-ch, RCA (Linear, 1KΩ)
Audio bitrate
64 Kbps
Dual-stream
Support
Stream type
Video, Video & Audio
Synchronous playback
4-ch
(up to 2-ch 1080P real time)
8-ch
(up to 2-ch 1080P real time)
Playback resolution
1080P / 720P / VGA / WD1 / 4CIF / CIF / QVGA / QCIF
Network
management
Remote connection
128
Network protocols
TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP,

HIKVISION Digital Video Recorder Specifications

General

Audio system	2-way
Product color	Black
Channels quantity	4 channels
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264, H.264+, H.265, H.265 Pro, H.265 Pro+
Analog signal format system	NTSC, PAL
Playback resolutions supported	1920x1080, 1280x1024, 1280x720, 1024x768, 704x480, 704x576
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Audio input	RCA
RS-485 ports	1
USB 2.0 ports quantity	2
DC voltage	12 V
Power consumption (typical)	18 W
HDD interface	Serial ATA, Serial ATA II, Serial ATA III
Maximum HDD capacity	10000 GB
Ethernet LAN	Yes
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF

Weight and Dimensions

Depth	242 mm
Width	315 mm
Height	45 mm
Weight	1160 g
