HIKVISION Digital Video Recorder Quick Operation Guide

Quick Operation Guide of Digital Video Recorder
21
Table 4 Specification for DS-7300HFHI-SL
NFS, iSCSI, UPnP™
Hard disk
SATA
2 SATA interfaces
Capacity
Up to 4 TB capacity for each disk
External
interfaces
Network interface
1; 10M / 100M / 1000M self-adaptive Ethernet interface
Serial interface
1; standard RS-485 serial interface, half-duplex
USB port
2 × USB2.0
Alarm in / out
(optional)
4 / 1
General
Power supply
12V DC
Consumption
(without hard disk)
Max. 15 W
Max. 20 W
Working temperature
-10 ºC ~ +55 ºC (14 ºF ~ 131 ºF)
Working humidity
10% ~ 90%
Chassis
19-inch rack-mounted 1U chassis
Dimensions
(W × D × H)
445 × 290 × 45 mm (17.5 × 11.4 × 1.8 inch)
Weight
(without hard disk)
4 kg / 8.8lb
Model
DS-7304HFHI-SL
DS-7308HFHI-SL
DS-7316HFHI-SL
Video/Audio
input
Video compression
H.264
HD-SDI video input
4-ch
8-ch
16-ch
HD-SDI interface (800 mVp-p, 75 Ω)
Supported HD-SDI
camera types
1080I60, 1080I50, 1080P30, 1080P25, 720P60, 720P50, 720P30,
720P25
Audio compression
G.711u
Audio input
4-ch, RCA (2.0 Vp-p, 1 KΩ)
Two-way audio in
1-ch, RCA (2.0 Vp-p, 1 KΩ)
Video/Audio
output
HDMI / VGA output
1920 × 1080 / 60 Hz ,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz,
1024 × 768 / 60 Hz
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC:
704 × 480
Encoding resolution
Main stream: 1080P (non-real-time) / 720P / VGA / WD1 / 4CIF /
CIF
Sub-stream: WD1 (non-real-time)/ 4CIF(non-real-time) / CIF /
QCIF / QVGA
Frame rate
Main stream: 1/16 fps ~ Real time frame rate
Sub-stream: 1/16 fps ~ Real time frame rate
Video bitrate
32 Kbps-6 Mbps
Audio output
2-ch, RCA (Linear, 1KΩ, for VGA output and CVBS output
respectively)

HIKVISION Digital Video Recorder Specifications

General

Audio system	2-way
Product color	Black
Channels quantity	4 channels
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264, H.264+, H.265, H.265 Pro, H.265 Pro+
Analog signal format system	NTSC, PAL
Playback resolutions supported	1920x1080, 1280x1024, 1280x720, 1024x768, 704x480, 704x576
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Audio input	RCA
RS-485 ports	1
USB 2.0 ports quantity	2
DC voltage	12 V
Power consumption (typical)	18 W
HDD interface	Serial ATA, Serial ATA II, Serial ATA III
Maximum HDD capacity	10000 GB
Ethernet LAN	Yes
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF

Weight and Dimensions

Depth	242 mm
Width	315 mm
Height	45 mm
Weight	1160 g
