Network Dome Camera·Quick Start Guide
27
27
Angle Adjustment of Type I Camera Figure 2-6
Tilting Adjust
Screw
Rotate: 0° to 355°
Pan:
to 355°
Tilt:
to 75°
Angle Adjustment of Type II Camera Figure 2-7
~360°
~65°
Tilting Adjust
Screw
