HIKVISION DS-2CD2443G0-IW Series User Manual

Network Cube Camera·Quick Start Guide
25
25
3. Install the fixed tray to the ceiling with the supplied screws.
4. Install the base to the fixed plate.
Install the Fixed Plate and Mounting Base Figure 3-7
5. Install the camera to the bracket.
Install the Camera Figure 3-8
6. Adjust surveillance angel
1). Loosen the knob to adjust the panning position and tilting
position.
2). After adjusting the angle of the camera to the desired
position, fasten the knob.
