Network Camera User Manual
109
Set up detection areas, density levels and linkage method on this page.
People Density Rule configuration
Steps:
1. Click and draw detection area on live image. Click to clear all the areas.
Note: You can set 8 areas at most, and the area can be set as polygon of 10 sides
at most.
2. Set target size as Large-size Target (40*40 pixel) or Small-size Target (20*20 pixel)
for each detection area from the dropdown list.
Note: Click or , a frame of 40*40 pixel or 20*20 pixel will be showed on
live picture. Choose the corresponding target size by comparing the target size
with frame size.
3. Set Density Level, including Number of People. Three levels can be configured in
total, and the density increases from level 1 to level 3.
Note: The number you input means the lower limit of each level. For example,
set the Number of People of Level 1 as 10, Level 2 is 100, and level 3 is 1000.
When the number of people in the detection area is less than 10, the alarm will
