Network Camera User Manual
110
not be triggered. When the number of people is between 10 and 100, Level 1
alarm will be triggered. When the number of people is between 100 and 1000,
Level 2 alarm will be triggered. When the number is above 1000, Level 3 alarm
will be triggered.
4. Click to save the settings.
5. Set the Arming Schedule.
1) Check Enable to edit the arming schedule.
2) Select the timeline of a certain day, and drag the left button of the mouse to
set the capture schedule (the start time and end time of the recording task).
3) (Optional) )After you set the scheduled task, you can click and copy the
task to other days.
4) Click Save to save the schedule.
6. Set the Linkage Method for People Density detection.
Note: Before you start, make sure the Data Uploading function has been enabled.
Go to Configuration > People Density > Data Upload to check the Enable Data
Uploading checkbox. The alarm actions will be triggered when the number of
people surpass the setting value in surveillance scene.
Check Enable to enable the function. Notify Surveillance Center is selectable.
Notify Surveillance Center: Send an exception or alarm signal to remote
management software when an event occurs.
Click Save to save the settings.
9.3.2 Data Upload
Configure the content and mode when upload to surveillance center.
Configure Data Upload
Steps:
1. Check Enable Data Uploading checkbox, and the data of people density
detection will be uploaded to surveillance center.
2. Check Enable Picture Uploading checkbox, the alarm will be uploaded to
surveillance center with pictures.
