HIKVISION DS-2CD6924G0-IHS User Manual

Network Camera User Manual
78
Audio Settings
2. Configure the following settings.
Note: Audio settings vary according to different camera models.
Audio Encoding: G.722.1, G.711 ulaw, G.711alaw, G.726, MP2L2 and PCM are
selectable. For MP2L2, the Sampling Rate and Audio Stream Bitrate are
configurable. For PCM, the Sampling Rate can be set.
Audio Input: MicIn and LineIn are selectable for the connected microphone and
pickup respectively.
Input Volume: 0-100 adjustable.
Environmental Noise Filter: Set it as OFF or ON. When the function is enabled,
the noise in the environment can be filtered to some extent.
3. Click Save to save the settings.
Display Info. on Stream
Check the checkbox of Enable Dual-VCA, and the information of the objects (e.g.
human, vehicle, etc.) will be marked in the video stream. Then, you can set rules on
the connected rear-end device to detect the events including line crossing, intrusion,
etc.
Display Info. on Stream

HIKVISION DS-2CD6924G0-IHS Specifications

General

Form factor	Dome
Mounting type	Ceiling
Product color	Black
Bluetooth	-
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
Sample rate	48 kHz
Bit rate range	16 - 192 Kbit/s
Audio formats supported	G.711, MP2L2, G.722.1, G.726, PCM
Total megapixels	- MP
Maximum resolution	6480 x 1080 pixels
Video formats supported	H.264, H.265
Supported graphics resolutions	1920 x 1080 (HD 1080), 3840 x 2160
Number of cameras	1
Fixed focal length	6 mm
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	20 m
Number of illumination LEDs	4
DC output voltage	12
Power source type	DC, PoE
Sensor type	CMOS
Operating temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	0 - 95 %
Pan range	0 - 355 °
Tilt angle range	0 - 90 °
Minimum illumination	0.003 lx
Type	IP security camera
Languages support	English
Placement supported	Indoor & outdoor
Connectivity technology	Wired
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	256 GB

Weight and Dimensions

Depth	207.63 mm
Width	189.5 mm
Height	206.62 mm
Weight	3000 g
Package type	Box
Package depth	261 mm
Package width	340 mm
Package height	293 mm
Package weight	5000 g
